Model | SR-200E | |
Temperature Range (In Container) | -18 ℃~+15℃ | |
Cooling Capacity | 0℃/+32℉ | 2600 W / 2235 Kcal |
-18℃/-0.4℉ | 1360 W / 1170 Kcal | |
Compressor | Model | HIGHLY DDH254 |
Voltage | 220V~450V DC | |
Weight | 19.2 kg | |
Condenser | Core | Aluminum micro-channel parallel flow core |
Fan | One fan | |
Airflow | 1800 m3 / h | |
Dimension | 1106*781*223 mm | |
Weight | 65 kgs | |
Evaporator | Core | Copper tube & aluminum fin |
Blower | One blower | |
Airflow | 800 m3 / h | |
Dimension | 611*522*182 mm | |
Expansion valve | Danfoss | |
Weight | 14.5 kgs | |
Emergency power supply | 220V-450V | |
Refrigerant | R404a / 1.3 kgs | |
Defrosting | Hot gas defrosting (Auto. / Manual) | |
Application | 5~7 m³ (176~247ft³) | |
![]() |
